Desktop label printer

Zebra ZT510

High-performance printers at an affordable price

High reliability in uninterrupted operation
Cost-effective by dispensing with unnecessary additional functions
Withstands the harshest manufacturing and storage environments
Can be easily integrated into existing networks
Link-OS for better transparency, management and maintenance
Many customisation options for future requirements

The Zebra ZT510 industrial printer offers an excellent price/performance ratio and combines all the important functions you expect from an industrial printer. Building on its proven predecessor, the 105SLPlus, the ZT510 impresses with its robust design and extended options for management and monitoring on site or remotely. You benefit from its reliable round-the-clock performance, long-lasting operation and additional functions that prepare you for future challenges.

Zebra ZT510 label print application warehouse in logistics

Zebra ZT510 label print application in harsh welding manufacturing environments

Zebra ZT510 label print application in harsh manufacturing environments

Zebra ZT510 label print application in the logistics packing station

With its all-metal design, rugged construction and sealed domed keys to prevent the accumulation of dust, dirt and moisture, the ZT510 is at home in today's harshest manufacturing and warehouse environments. Designed to withstand many years of continuous use, this rugged tool can withstand extreme temperatures, dirt, rough handling and more.

Zebra's highly intelligent, best-in-class Link-OS environment provides greater insight into the real-time status and functionality of your print processes. With Link-OS, you can manage routing, firmware updates, printer configurations and more locally or remotely with a single cloud-based application. And with applications such as Virtual Devices, Profile Manager, Near Field Communication (NFC) and Print Touch, it is easy to integrate, update and contact support.

The ZT510 has a range of connectivity options, e.g. USB, serial, Gigabit Ethernet and Bluetooth® LE, making it easy to integrate into existing systems and connect to various networks. A parallel interface, 802.11a/c with Bluetooth® 4.0, USB host and IPv6 are also available as options.

From the fast processor that enables fast throughput of even complex graphics, to the optional, easily accessible USB host card slot at the rear of the printer: The ZT510 optimises performance wherever possible. And dynamic QR codes provide additional web-based support on demand to quickly resolve printer faults.

Technical specifications

Features

Flash memory expansion as an option

–

PDF direct printing

Display

LCD Display

Printhead technology

Flathead

Programming language

ZPL2

ROM / flash memory

2 GB

SD memory card slot

–

Technical values

Printing process

Thermal transfer, Thermal direct

Print width

104 mm

Printhead resolution

203 dpi, 300 dpi

Print speed up to

305 mm/sec

Label width

20 - 114 mm

Print media

Material width max (labels and liner)

114 mm

Material width min (labels and liner)

20 mm

Maximum material thickness

0.305 mm

Ribbon

Width

51 - 110 mm

Inner core diameter

25.4 mm

Maximum length

450 linear meters

Winding

Outside

Physical aspects

Printer dimensions (HxWxL)

396 mm x 268 mm x 512 mm

Weight

22,7 kg

Authorisations

CE, FCC, ICES-003, CCC

Rel. humidity non-condensing

20 - 85 %

Ambient temperature

0 - 40°C

Supply voltage

90 - 265 V

Frequency

47 - 63 Hz
