Print-Apply Labeling System

Legi-Air 4050RR

Smart 2-sided labeling in a single run

Flexible: 1 or 2-sided labeling possible
Tool-free format change with Quick-Change
Contactless labeling with Tamp-Blow
Precise: Accuracy of label placement up to ±2 mm
Print resolution up to 600 dpi, fast & sharp
Compact design, CE-compliant and safe

The Legi-Air 4050RR is a highly flexible labeling system for automated 1- or 2-sided labeling of carton packaging - ideal for industries such as pharmaceuticals, food and home care. Thanks to its compact design and the ingenious Rombid rotation system, the applicator enables precise label placement even with changing labeling modes - without mechanical modification. Thanks to the quick-change adapter, format changes are quick and tool-free. The tamp-blow process guarantees non-contact label application, with the tamp always parallel to the product surface. Print speeds of up to 400 mm/s and resolutions of up to 600 dpi ensure razor-sharp results - even with variable print data. Whether single or double-sided labeling: The Legi-Air 4050RR stands for process reliability, flexibility and quality in industrial labeling.

The centerpiece of the Legi-Air 4050RR is a rotary swing arm with two axes, which enables labeling on the front, side, or back of the carton. The applicator and tamp rotate independently of each other, ensuring that the tamp always remains parallel to the product surface. This guarantees precise label placement even with complex product positions or varying carton orientations. The result: maximum precision and flexibility in a wide range of logistics and production environments.

With tamp-blow technology, the label is transferred onto the product surface by means of a precise jet of air – completely without direct contact. This method reliably protects delicate or sensitive surfaces from damage while also enabling high labeling speeds. The process guarantees consistently high quality, even in demanding applications, and significantly reduces maintenance requirements compared to mechanical application solutions.

The quick-change adapter makes it possible to change labeling formats quickly, easily, and completely without tools. The labeling tamp can also be replaced in no time at all. This high level of flexibility significantly reduces downtime and saves valuable setup time. Especially in production environments with frequent product changes, dynamic requirements can thus be met efficiently while ensuring consistently high process reliability.

With the optional trigger selection box, different labeling modes can be easily preset - from front and side labeling to 2-sided labeling. The box allows the integration of several sensors and interfaces, so that the 4050RR can be easily adapted to different batches, processes and requirements - without any changeover.

RR Applicator

Rotary applicator with two axes of rotation for double-sided labeling

Function	blow-on, tamp-on
Drive concept applicator	Stepper motor
Rotation arm length	195 mm - 195 mm

Zebra ZE511

Highest printing performance for industrial applications

Print width	104 mm
Print speed up to	457 mm/sec
Printhead resolution	203 dpi, 305 dpi, 609 dpi
Printing process	Thermal transfer, Thermal direct, RFID

Zebra ZE521

Highest printing performance for industrial applications

Print width	168 mm
Print speed up to	356 mm/sec
Printhead resolution	203 dpi, 305 dpi
Printing process	Thermal transfer, Thermal direct, RFID

Sato S84NX

Precise, fast and reliable industrial printing

Print width	104 mm
Print speed up to	406 mm/sec
Printhead resolution	203 dpi, 305 dpi, 609 dpi
Printing process	Thermal transfer, Thermal direct, RFID

Sato S86NX

Precise, fast and reliable industrial printing

Print width	167.5 mm
Print speed up to	355.6 mm/sec
Printhead resolution	203 dpi, 305 dpi
Printing process	Thermal transfer, Thermal direct, RFID

CAB PX Q4

High-precision print module for automated labeling in industry and logistics

Print width	108.4 mm
Print speed up to	300 mm/sec
Printhead resolution	203 dpi, 305 dpi, 609 dpi
Printing process	Thermal transfer, Thermal direct

CAB PX Q6

High-precision print module for automated labeling in industry and logistics

Print width	168 mm
Print speed up to	250 mm/sec
Printhead resolution	203 dpi, 305 dpi
Printing process	Thermal transfer, Thermal direct

Novexx XDM 944

Maximum speed for industrial labeling

Print width	106 mm
Print speed up to	400 mm/sec
Printhead resolution	300 dpi
Printing process	Thermal transfer, Thermal direct

Novexx XDM 945

Maximum speed for industrial labeling

Print width	128 mm
Print speed up to	350 mm/sec
Printhead resolution	305 dpi
Printing process	Thermal transfer, Thermal direct

Novexx XDM 946

Maximum speed for industrial labeling

Print width	160 mm
Print speed up to	300 mm/sec
Printhead resolution	305 dpi
Printing process	Thermal transfer, Thermal direct

LDM 180

Efficient dispensing module for use without printing

Technical specifications

Application data

Label position

Side, Top, Front, reverse side, Front side on both sides & side, Double-sided back & page, Front side on both sides & top side, Reverse side on both sides & top side

Labeling mode

in stop mode, throughfeed

Label application rate max.

25 1/min

Positioning accuracy

2 mm

Label size min.

30 mm x 20 mm

Label size max.

160 mm x 120 mm

Label roll diameter max.

300 mm
